PXIe Jetson AGX Xavier Module

PART NUMBER : DE160200

The PXIe Jetson AGX Xavier Module is a high-performance edge AI platform designed to meet the computational demands of next-generation AI applications. Built around NVIDIA’s powerful Jetson AGX Xavier system-onmodule (SoM), this module is optimized for real-time processing and advanced AI workloads, including computer vision, deep learning, and sensor data analysis. By integrating this SoM into the PXIe form factor, the module provides a flexible, modular solution for industries requiring high-performance edge computing.

Overview

A standout feature of the PXIe Jetson AGX Xavier Module is its Add-on Board Connector, which allows users to expand and customize the platform by adding Add-on Boards. The integration of specialized hardware, such as GMSL2 and 3G-SDI interfaces is enabled by this connector through custom-designed Add-on Boards. The signals for these high-bandwidth interfaces are routed directly from the Jetson platform, ensuring seamless communication and fast data transfer between the module and external sensors or devices.

This modular approach gives users the flexibility to tailor the system to specific project needs, adding new capabilities as required without redesigning the entire platform. The ability to add GMSL2 and 3G-SDI interfaces through Add-on Boards allows the system to handle high-bandwidth sensor data streams and video signals, making it ideal for applications such as real-time video processing, autonomous vehicles, industrial IoT, and surveillance systems.

The PXIe Jetson AGX Xavier Module includes the powerful GPU, deep learning processors, and an octa-core ARM CPU required to run complex AI models directly at the edge. This enables real-time decision-making with minimal latency, reducing the reliance on cloud infrastructure and ensuring faster response times in critical applications.

Key Features

Jetson AGX Xavier SoM Integration: Powered by the NVIDIA Jetson AGX Xavier SoM, which includes a high-performance GPU, AI processors, and an octa-core ARM CPU, optimized for edge AI workloads.
A PXIe Form Factor: Modular design that fits into the PXIe chassis, providing an ideal solution for scalable edge AI systems and easy integration into larger test and measurement environments.
A Add-on Board Connector: Supports the addition of Add-on Boards, enabling the integration of specialized features like GMSL2 and 3G-SDI interfaces. These high-bandwidth interfaces are routed from the Jetson platform via the Add-on Boards, allowing for flexible customization.
A Edge AI Optimization: Designed to run AI algorithms locally at the edge, minimizing data transfer to the cloud and reducing latency for faster, real-time processing.
A Customizable and Scalable: The modular design allows users to expand the platform with custom Addon Boards to meet specific project requirements and ensure scalability for a wide range of applications.

Downloads

DE160200_Brochure

Download

DE160200_Datasheet

Download
